About Aditya Shade Systems
A linear sequence in which the initial architectural shape is transmitted to the engineering office in charge of the structural design are followed by the design of traditional rigid structures ; Subsequently in accordance with the structural requirements once the architectural shape has been upgraded , for the realisation of the construction the definitive project is transmitted to the builders.The correlation between the several subjects is generally reduced to the correct information transfer between two consecutive phases.
The design process of tension membranes can be summarised in three main
steps: the form-finding, the static analysis and the patterning, with the possible addition of dynamic analysis if required.
The design development phase of a Tensile membrane structure project usually revolves around a collaborative effort often involving client, architect, engineer, head contractors and fabricator. The first step is to determine the boundaries of the Tensileed structure. Boundaries consistof walls + beams + trees + fences + Columns + Cables heights + substrata services and composition. Question arises what does the structure need to acheive eg. high visibility, weather protection, screening etc.
The fabric is either continuously fixed to walls or beams or attached to columns. Between Connection points where cable or webbing is required for carrying loads over major structural points, fabric forms curved edge or “a catenary curve”. Catenaries are usually curved inward from 7 to 15 of the total length of the span. After determination of parameters the next step is of developing design. This could involve either a basic design or computer aided design.
Our Philosophy
Our Missions
Our Vision
Our Values
Designing Shades for the home :
Where a design is straightforward in the case of small projects , a sketch can be prepared , with parameters , measurements , fabric selection and cost determined quite expediently. Irrespective of the size of the project there are fabrication , stringent design and installation guidelines to be followed. Usually with smaller structures , the clients looking towards the installer for direction and expertise that compliance , skill and quality training are particularly important. Design factors to consider on domestic work are site access, weather protection needed, council requirements, options and availability of materials, impact of underground services on the location of structure and explanation of the design to the client. As not all Abacus Shade structure projects are complex all projects are engineered , carry warranties , are perrformed by trained personnel and adhere to statutory requirements.
